6 Technical Data
6.2 Specific rated operational data
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 137
DC1-32… device series
Continue
Size Symbol unit
011 018 024 030 046
Rated operational current I
e
A 10.5 18 24 30 46
Overload current for 60 s every 600 s i
l
A
15.75 27 36 45 69
Starting current for 2 s every 20 s A
18.38 31.5 42 52.5 80.5
Apparent power at rated operation
230 V
SkVA
4.18 7.17 9.55 11.94 18.30
Apparent power at rated operation
240 V
SkVA
4.36 7.48 9.96 12.46 19.10
Assigned motor power
at 230 V, 50 Hz P kW 2.2 4 5.5 7.5 11
at 220 - 240 V, 60 Hz P HP
3 5 7.5 10 15
Power side (primary side):
Number of phases 3 3 3 3 3
Rated operating voltage U
LN
V
200 - 10 % - 264 + 10 %, 50/60 Hz
180 - 264 ±0 %, 48 - 62 Hz ±0 %
Input current (phase current) I
LN
A
12.1 20.9 26.4 33.3 50.1
Minimum braking resistance R
B
Ω
50 25 20 15 10
Switching frequency (pulse frequency)
Default Setting f
PWM
kHz 16 8 8 8 8
Setting range f
PWM
kHz
4 -32 4 -24 4 -24 4 -24 4 -24
Maximum leakage current to earth
(PE),
Without motor
I
PE
mA
< 1 < 1 2.49 2.49 2.49
Efficiency η
0.96 0.96 0.97 0.97 0.96
Heat dissipation at I
e
(150 %) P
V
CO
90.2 160 223 304 446
fan, built-in
✓ ✓ ✓ ✓ ✓
Size
FS2 FS3 FS3 FS4 FS4
