6 Technical Data
6.2 Specific rated operational data
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 139
DC1-34…device series
Continue
Size Symbol Unit
014 018 024 030 039 046
Rated operational current I
e
A 14 18 24 30 39 46
Overload current for 60 s every 600 s i
l
A
21 27 36 45 58.5 69
Starting current for 2 s every 20 s A
24.5 31.5 42 52.5 68.25 80.5
Apparent power at rated operation
400 V
SkVA
9.67 12.47 16.63 20.76 26.99 31.83
Apparent power at rated operation
480 V
SkVA
11.64 14.96 19.95 24.91 32.39 38.20
Assigned motor power
at 400 V, 50 Hz P kW 5.5 7.5 11 15 18.5 22
at 440 - 480 V, 60 Hz P HP
7.5 10 15 20 25 30
Power side (primary side):
Number of phases 3 3 3 3 3 3
Rated operating voltage U
LN
V
380 V - 10 % - 480 V + 10 %, 50/60 Hz
342 - 528 V ±0 %, 48 - 62 Hz ±0 %
Input current (phase current) I
LN
A
17.2 21.2 27.5 26.4 33.3 50.1
Minimum braking resistance R
B
Ω
100 80 50 30 22 22
Switching frequency (pulse frequency)
Default Setting f
PWM
kHz 8 8 8 8 8 8
Setting range f
PWM
kHz
4 - 24 4 - 24 4 - 24 4 - 24 4 - 24 4 - 24
Maximum leakage current to earth
(PE),
Without motor
I
PE
mA
< 1 < 1 2.49 2.49 2.49 2.49
Efficiency η
0.96 0.97 0.97 0.97 0.97 0.96
Heat dissipation at I
e
(150 %) P
V
CO
223 304 446 607 728 801
fan, built-in
✓ ✓ ✓ ✓ ✓ ✓
Size
FS3 FS3 FS3 FS4 FS4 FS4
