6 Technical Data
6.5 Fuses
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 147
Mains voltage 400 V
Supply voltage (50/60 Hz) U
LN
380 (-10 %) - 480 (+10 %) V
U
e
400 V AC, three-phase / U
2
400 V AC, three-phase
   
DC1-342D2…
3.5 6 FAZ-B6/3 PKM0-6.3 6D27 6 LPJ-6SP
DC1-344D1NN…
5.6 10 FAZ-B10/3 PKM0-10 10D27 10 LPJ-10SP
DC1-344D1FN…
5.6 10 FAZ-B10/3 PKM0-10 10D27 10 LPJ-10SP
DC1-344D1NB…
5.6 10 FAZ-B10/3 PKM0-10 10D27 10 LPJ-10SP
DC1-344D1FB…
5.6 10 FAZ-B10/3 PKM0-10 10D27 10 LPJ-10SP
DC1-345D8…
7.5 16 FAZ-B16/3 PKM0-16 16D27 10 LPJ-10SP
DC1-349D5…
11.5 16 FAZ-B16/3 PKM0-16 16D27 15 LPJ-15SP
DC1-34014…
17.2 25 FAZ-B25/3 PKM0-25 25D33 25 LPJ-25SP
DC1-34018…
21.2 32 FAZ-B32/3 PKM0-32 35D33 30 LPJ-30SP
DC1-34024…
27.5 40 FAZ-B40/3 PKZM4-40 40D33 35 LPJ-35SP
DC1-34030…
34.2 40 FAZ-B40/3 PKZM4-40 40D33 45 LPJ-45SP
DC1-34039…
44.1 50 FAZ-B50/3 PKZM4-50 50D33 60 LPJ-45SP
DC1-34046…
51.9 63 FAZ-B63/3 PKZM4-63 63D33 70 LPJ-70SP
Device Type Input current Fuse or miniature circuit-breaker
I
LN
IEC (Type B or gG) UL (Class CC or J)
A A Eaton type A Eaton type
