6 Technical Data
6.10 Motor chokes
162 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
DC1-342D2…
2.2 DX-LM3-005 4.8 DX-LM3-005 5
DC1-344D1…
4.1 DX-LM3-005 4.8 DX-LM3-005 5
DC1-345D8…
5.8 DX-LM3-008 7.6 DX-LM3-008 8
DC1-349D5…
9.5 DX-LM3-011 10.5 DX-LM3-011 11
DC1-34014…
14 DX-LM3-016 15.2 DX-LM3-016 16
DC1-34018…
18 DX-LM3-035 33.3 DX-LM3-035 35
DC1-34024…
24 DX-LM3-035 33.3 DX-LM3-035 35
DC1-34030…
30 DX-LM3-035 33.3 DX-LM3-035 35
DC1-34039…
39 DX-LM3-050 47.5 DX-LM3-050 50
DC1-34046…
46 DX-LM3-050 47.5 DX-LM3-050 50
1) f
PWM
switching frequency ≤ 12 kHz (rms) → DC1 variable frequency drive setting: ≤ 24 kHz
in parameter P-17 (double modulation)
For more information and technical data on DX-LM3…
motor chokes, please refer to instruction leaflet
IL00906003Z.
Device Type
Rated
operational
current
Motor choke (three-phase) that should be used
Max. U
LN
: 750 VAC +0%; max. f
2
: 400 Hz
Maximum f
PWM
switching frequency: 12 kHz (rms)
1)
Maximum ambient temperature: 70
o
C
Type (max. 50
o
C) Type (max. 40
o
C)
I
e
I
e
I
e
A A A
