1.4 Rated operational data
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 19
1.4.3.3 DC1-32… device series
Mains voltage: 3 AC 220 - 240 V (±10 %), 50/60 Hz
Output voltage: 3 AC 220 - 240 V, 50/60 Hz
Type
Rated operational current
Assigned Instance
Motor Power
Display (operating unit) Local controls Radio interference suppression filter Degree of protection Size Brake chopper
I
e
P
1)
(230 V,
50 Hz)
P
2)
(220
- 240 V,
60 Hz)
A kW HP
DC1-322D3NN-A20N 2.3 0.37 1/2 LED – – IP20 FS1 –
DC1-322D3NN-A66N
2.3
3)
0.37 1/2 LED – – IP66 FS1 –
DC1-322D3NN-A6SN
2.3
3)
0.37 1/2 LED ✓ – IP66 FS1 –
DC1-324D3NN-A20N
4.3 0.75 1 LED – – IP20 FS1 –
DC1-324D3NN-A66N
4.3
3)
0.75 1 LED – – IP66 FS1 –
DC1-324D3NN-A6SN
4.3
3)
0.75 1 LED ✓ – IP66 FS1 –
DC1-327D0NN-A20N
7 1.5 2 LED – – IP20 FS1 –
DC1-327D0NB-A20N
7 1.5 2 LED – – IP20 FS2 ✓
DC1-327D0FB-A20N
7 1.5 2 LED – ✓ IP20 FS2 ✓
DC1-327D0NN-A66N
7
3)
1.5 2 LED – – IP66 FS1 –
DC1-327D0NB-A66N
7
3)
1.5 2 LED – – IP66 FS2 ✓
DC1-327D0FB-A66N
7
3)
1.5 2 LED – ✓ IP66 FS2 ✓
DC1-327D0NN-A6SN
7
3)
1.5 2 LED ✓ – IP66 FS1 –
DC1-327D0NB-A6SN
7
3)
1.5 2 LED ✓ – IP66 FS2 ✓
DC1-327D0FB-A6SN
7
3)
1.5 2 LED ✓ ✓ IP66 FS2 ✓
DC1-32011NB-A20N
10.5
6)
2.2 3 LED – – IP20 FS2 ✓
DC1-32011FB-A20N
10.5
6)
2.2 3 LED – ✓ IP20 FS2 ✓
DC1-32011NB-A66N
10.5
6)
2.2 3 LED – – IP66 FS2 ✓
DC1-32011FB-A66N
10.5
6)
2.2 3 LED – ✓ IP66 FS2 ✓
DC1-32011NB-A6SN
10.5
6)
2.2 3 LED ✓ – IP66 FS2 ✓
DC1-32011FB-A6SN
10.5
6)
2.2 3 LED ✓ ✓ IP66 FS2 ✓
DC1-32018NB-A20N
18 4 5 LED – – IP20 FS3 ✓
DC1-32018FB-A20N
18 4 5 LED – ✓ IP20 FS3 ✓
DC1-32018NB-A66N
18
5)
4 5 LED – – IP66 FS3 ✓
DC1-32018FB-A66N
18
5)
4 5 LED – ✓ IP66 FS3 ✓
DC1-32018NB-A6SN
18
5)
4 5 LED ✓ – IP66 FS3 ✓
DC1-32018FB-A6SN
18
5)
4 5 LED ✓ ✓ IP66 FS3 ✓
