3 Installation
3.3 Mounting
64 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
Dismantling from mounting rails
To remove the device, push down the spring-loaded clip. A cutout
marked on the lower edge of the device is provided for this purpose.
A flat-bladed screwdriver (blade width 5 mm) is recommended for
pushing down the clip.
Figure 30: Dismantling from mounting rails
