Connection

• Connect Time: The wait time to connect to the grid if the solar input is ready and the grid

power is in range of the voltage and frequency settings below.

• Reconnect Time: The inverter will attempt to reconnect to the grid after abnormal situations

(i.e. voltage/frequency fluctuations) once this amount of time has elapsed.

• Grid Connect Condition Settings: If the voltage and frequency is in range of the below set-

tings, the inverter will connect to grid.

o Grid Volt Connect High (V)

o Grid Volt Connect Low (V)

o Grid Freq Connect High (Hz)

o Grid Freq Connect Low (Hz)

Power Command

• Active Power Percent (%): Max AC Output power percent of the inverter.

• OVF Load Derate Enable: If the frequency is higher than 50.2/60.2Hz, the output power will

be reduced according to a linear derating curve.

• Reactive Power Type

• PF CMD

• Reactive Power Percent(%)

Grid Protection

• Grid Volt Limit 1-3 Low(V): Minimum acceptable grid voltage for inverter(s).

• Grid Volt Limit 1-3 High(V): Maximum acceptable grid voltage for inverter(s).

• Grid Freq Limit 1-3 Low(Hz): Minimum acceptable grid frequency for inverter(s).

• Grid Freq Limit 1-3 High(Hz): Maximum acceptable grid frequency for inverter(s).

• Grid Volt Mov Avg High(V)

• Power Soft Start Slope(%/min): The rate at which the inverter will reactivate Grid Input

after an outage.

• Grid Soft Start: Enable or disable Grid Soft Start. If enabled, the inverter will output AC

power more slowly than under normal conditions.
