14 Technical Specifications
AC Input Data
Nominal AC Voltage
240 | 208VAC
Frequency
50/60Hz
Max. Continuous AC Current
50A
AC Grid Output Data
Max. Continuous Output Current
50A
AC Bypass (Grid)
200A
Rated Voltage
240VAC
Operating Voltage Range
180–270VAC
Nominal Power Output (W)
@240V 12kW/@208V 10.4kW
Operating Frequency
50/60Hz
Phase Shift
0.99@ full load
Reactive Power Adjust Range
(-0.8) – (+0.8) leading adjustable
Sync Inrush Current
35A
Backup/UPS AC Output Data
Rated Output Current (240V/208V)
50A
AC Bypass (Generator)
90A
Nominal Output Voltage (V)
240 | 120/240 | 120/208 VAC
Rated Output Power (W)
@240VAC 12kW/@208VAC 10.4kW
Max Cont. Line Wattage
8kW per 120V
Peak Power (W)
With PV: 14.7kW (10 min), 15.5kW (5 min)
Without PV: 13.5kW (10 min)
Operating Frequency
50/60Hz
THDV (Total Harmonic Distortion Voltage)
<5%
Switching Time
10ms
PV Input Data
Number of MPPTs
3
Inputs per MPPT
2/1/1
Nominal Input Current
25/15/15A
Max. Short Circuit Input Current
31/19/19A
DC Input Voltage Range
100–600 VDC
Unit Startup Voltage
100 VDC
Load Output Minimum Voltage
>140 VDC
MPP Operating Voltage Range
120–500 VDC
Full Power MPPT Voltage Range
230–500 VDC
Nominal MPPT Voltage
360 VDC
Maximum Utilized Solar Power
18kW
Recommended Maximum Solar Input
21kW

EG4 18KPV Specifications

General

Model	EG4 18KPV
Category	Inverter
Rated Power	18 kW
Max. AC Output Current	75A
Surge Power	36 kW
Number of MPPTs	2
Frequency	50/60 Hz
Operating Temperature	-25°C to 60°C
Warranty	5 years
Output Voltage	120/240VAC
Communication	RS485
Cooling	Fan
Weight	77 lbs (35 kg)
Dimensions	670 x 530 x 220 mm
