4.6

Working with a Generator

4.6.1 Generator System Connection

This hybrid inverter can work with a generator. There are GEN terminals on the inverter for connecting

the generator. When the generator is started, it will supply the inverter with the generator’s max.

power. If the generator’s power is not adequate to power all loads, the inverter will pull from batteries

as supplemental power.

Generator requirements:

1. Generator should be a 120/240VAC, 60 Hz generator.

2. Generator capacity should be between 6 – 21.6kW.

Extending the CT Clamp Cable

The CT wires can be extended with a common

ethernet cable if they are not long enough. An RJ45

adapter is needed for the extension. The CT wires

can be extended up to 300 ft. (around 100 m).
