14
4.4
PV Connection
4.4.1 Connecting PV to the Inverter
Cable Requirements:
Minimum Insulator Voltage
10 AWG – 6AWG (Max) (6 mm
2
– 16 mm
2
) 600V
Consult with your installer to ensure that appropriate cable sizing is used due to various factors such as
voltage drop and VOC.
Reminder
Verify the lowest ambient temperature of the installation location. The rated VOC on the solar module
nameplate is obtained at STC (77°F/25°C). As the ambient temperature drops, the solar module VOC
increases. Please ensure the maximum solar string voltage, corrected at the lowest temperature, does
not exceed the inverter’s maximum input voltage of 600V.
PV Input Data Description Parameter
DC Input Voltage Range
Range required for the unit to operate up to max input
100–600 VDC
Unit Startup Voltage
Voltage needed for the LCD to turn on
100 VDC
Load Output Minimum Voltage
Minimum voltage needed to output power on Load side
>140 VDC
MPP Operating Voltage Range
Range where the MPPT can track
120–500 VDC
Full Power MPPT Voltage Range
Range where the MPPT operates at max capabilities
230–500 VDC
Nominal MPPT Voltage
The MPPT will operate most optimally at this voltage
360 VDC
Maximum Utilized Solar Power
Number of watts the unit can utilize from array after
sidering all power loss factors
18,000W
Rec. Maximum Solar Input
The suggested PV power input into the device for it to uti-
lize the full 18kW of PV that it can process.
21,000W
