Electroline Control Unit IV - Figure 1-1: the Control Units Role in a Cable TV Network

Control Unit IV Reference Manual Product Description
529-0004 Ver.3 1-3
STT
STT
STT
TV signals and other
services (e.g. Internet)
Apartment
building
Apartment
building
FSK carrier
To next
addressable tap
Subscriber
drops
Subscriber
drops
Cable Headend
Control Unit
Billing system
Cable Network with Addressable Taps
RS-232 or
LAN connection via an
Ethernet-RS-232 bridge
Figure 1-1: The Control Unit’s role in a cable TV network
