Control Unit IV Reference Manual Setup
529-0004 Ver.3 3-13
Parity
The following table shows the fields found in the Control Unit’s setup menus. The data
shown in boldface type indicates the recommended values. These values are preset in the
factory but can be modified.
Table 3-4: Data configurations possible on COM ports 1 and 2
Parity Data bits Stop bits
No parity 8 1
No parity 8 2
No parity 7 1
No parity 7 2
Odd 7 1
Odd 7 2
Even 7 1
Even 7 2
To modify the parity:
1. At the COM) prompt, type
2
and press <Enter>. This will display the Parity options and
the current port settings.
COM)2
1-No parity
2-Odd
3-Even
?-Display menu
q-Quit and return
COM 1=9600 bps, NO parity, 8 data bits, 1 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
PAR)
2. Type the number (1 to 3) that corresponds to the desired parity (see Table 3-4) and press
<Enter>. The new values are displayed confirming the modification.
COM 1=9600 bps, ODD parity, 8 data bits, 1 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
3. Type
q
and press <Enter> to go back to the COM port menu.
