To modify the flavor:
1. At the COM) prompt, type
7
and press <Enter>. This will display the Flavor options and
the current port settings.
COM)7
1-Base
2-Ext A
3-Ext B
4-Ext C
?-Display menu
q-Quit and return
COM 1=9600 bps, NO parity, 8 data bits, 1 stop bit(s),
NO flow control, Protocol: ICOR, Flavor: Base
FLV)
2. Type the number (1 to 4) that corresponds to the desired flavor and press <Enter>. Note
that if you go back to the protocol menu and change the parent protocol, the flavor
remains the same. The system does not validate the protocol-flavor combination. Refer to
Table 3-6 to make sure you are using the right flavor.
The new values are displayed to confirm the modification.
COM 1=9600 bps, NO parity, 6 data bits, 2 stop bit(s),
NO flow control, Protocol: ICOR, Flavor: Ext A
3. Type
q
and press <Enter> to go back to the COM port menu.
3.6.7 RF watchdog setting for a single Control Unit
The role of the watchdog is to monitor the Control Unit’s modulator. It samples the messages
on the RF carrier that is received on the
TEST IN
and checks for errors.
If there is only one Control Unit and the RF watchdog is set to toggle on error, the Control
Unit will reset if an error occurs by warning the CPU.
Note:
Make sure that the Control Unit’s test ports are connected with a short coaxial cable jumper
that runs from the
TEST OUT
connector to the
TEST IN
connector.
This procedure sets the RF watchdog as recommended for a single master Control Unit with
no backup unit. For instructions on setting the watchdog for a redundancy system,
see section 3.7.5.
