Electroline Control Unit IV - Page 56

Setup Control Unit IV Reference Manual
3-14 529-0004 Ver.3
Data bits
For the default values of the data bits, refer to Table 3-4 on page 3-13.
To modify the data bits:
1. At the COM) prompt, type
3
and press <Enter>. This will display the Data bits options
and the current port settings.
COM)3
1-5
2-6
3-7
4-8
?-Display menu
q-Quit and return
COM 1=9600 bps, NO parity, 8 data bits, 1 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
WRD)
2. Type the number (1 to 4) of the desired data bit option and press <Enter>. The new
values are displayed, confirming the modification.
COM 1=9600 bps, NO parity, 7 data bits, 1 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
3. Type
q
and press <Enter> to go back to the COM port menu.
Stop bits
For the default values of the stop bits, refer to Table 3-4 on page 3-13.
To modify the stop bits:
1. At the COM) prompt, type
4
and then press <Enter>. This will display the Stop bits
options and the current port settings.
COM)4
1-1
2-1.5
3-2
?-Display menu
q-Quit and return
COM 1=9600 bps, NO parity, 8 data bits, 1 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
STP)
