Control Unit IV Reference Manual Setup
529-0004 Ver.3 3-15
2. Type the number (1 to 3) that corresponds to the stop bit choice and press <Enter>. The
new values are displayed, confirming the modification.
COM 1=9600 bps, NO parity, 8 data bits, 2 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
3. Type
q
and press <Enter> to go back to the COM port menu.
Handshaking (flow control)
To modify the handshaking type:
1. At the COM) prompt, type
5
and press <Enter>. This will display the Handshaking
options and the current port settings.
COM)5
1-None
2-CTS/RTS
?-Display menu
q-Quit and return
COM 1=9600 bps, NO parity, 8 data bits, 1 stop bit(s),
NO flow control, Protocol: Terminal, Flavor: Base
HND)
2. Type the number (1 or 2) of the desired flow control choice and press <Enter>. Selecting
CTS/RTS means that you want to use hardware flow control. The new values are
displayed, confirming the modification.
COM 1=9600 bps, NO parity, 8 data bits, 1 stop bit(s),
CTS/RTS flow control, Protocol: Terminal, Flavor: Base
3. Type
q
and press <Enter> to go back to the COM port menu.
