Control Unit IV Reference Manual Maintenance
529-0004 Ver.3 5-17
4. Put the switch on the programming adapter to the correct position:
MOD
5 to
program the
modulator’s frequency or
DEMOD
5
to program the demodulator’s frequency.
Note:
The modulator and the demodulator frequency of a Control Unit with a dual FSK
carrier cannot be programmed.
5. See the Electroline Addressable System Programmer/Monitor for Workabout
(EAS-PMW) User Guide for instructions on modulator/demodulator frequency
programming. Note that the frequency has to be within the Control Unit’s range (range
appears next to the
RF OUT
port on the unit’s rear panel) and the modulator and
demodulator must be programmed to the same frequency. Also, remember to update the
frequency label on the back panel of the unit once you have changed it.
