- Door safety interlock
- Wash solenoid, if the water in
the tub is not enough to cover
the heating element
- Heating element
- Recirculation pump
Door closed
Water level above
the heating element
Maximum time 10 min.
up to 90 °C (*)
Reheating
Circulation
Temperature in
°C measured
using the
NTC probe
- Door safety interlock
- Wash solenoid, if the water in
the tub is not enough to cover
the heating element
- Motor (55 rpm clockwise,
55 rpm anti-clockwise,
250 rpm pulse)
Door closed
Water level above
the heating element
Check for leaks
from the tub.
Drum speed
in rpm/10
- Door safety interlock
- Drainage pump
- Motor up to 650 rpm then
at maximum spin speed (**)
Door closed
Water level lower
than anti-boiling level
for spinning
Drain, calibration
of analogue
pressure switch
and spin.
Drum speed
in rpm/10
----- ----- ----- -----
Reading/Deleting the last alarm ----- ----- -----
- The LEDs light up in sequence,
the symbols on the LCD display
light up in in groups and the
backlighting comes on
- Touch a sensor to turn on the
group of icons in the LCD
screen or the corresponding
LED and the buzzer sounds
at the same time
Always active
User interface
functions
(*) In most cases, this time is sufficient to check the heating. However, the time can be increased by repeating the phase without draining the
water: pass for a moment to a different phase of the diagnostic cycle and then back to the heating control phase (if the temperature is higher
than 80 °C, heating does not take place).
(**) The check at the maximum speed occurs without control of the A.G.S. and no garments must be inside the appliance.
