Technical Support - MDM
75/104
599 77 39-16 Rev. 00
Lubricate the outside of the detergent dispenser.
Lubricate the inside of the bellow seal detergent inlet pocket.
First task to perform:
Gently insert the part of the detergent dispenser indicated by the arrow into
the detergent inlet pocket of the bellows seal.
Second task:
With one hand inside the appliance door, hold the bellow seal detergent inlet pocket still and gently insert the rest
of the detergent dispenser.
14.2.7 Upper counterweight
Remove the worktop (see relevant paragraph).
Remove the three screws that secure it to the welded tub.
When reassembling:
If the tub assembly is new, tighten the screws at a torque of 20 Nm.
If the tub assembly is new, tighten the screws at a torque of 15 Nm.
