Technical Support - MDM
62/104
599 77 39-16 Rev. 00
13.2
Key to operating circuit diagram EWX13611 (with universal motor)
Appliance electrical components PCB components
1. Main electronic circuit board
2. Door safety interlock
3. Electronic pressure switch
4. NTC
5. Pre-wash solenoid valve
6. Wash solenoid valve
7. Universal motor
7a. Tachometric (motor)
7b. Stator (motor)
7c. Rotor (motor)
7d. Thermal cut-out (motor)
8. Heating element
9. Display board
10. Drainage pump
DRAIN_TYS Drain pump TRIAC
DOOR_TY Door interlock TRIAC
PWELT_TY Pre-wash solenoid TRIAC
WELV_TY Wash solenoid TRIAC
MOTOR TY Motor TRIAC
K1 Clockwise rotation motor relay
K2 Anti-clockwise rotation motor relay
K3 Spin speed motor relay
K5 Heating element relay
