Electrolux EWX11831 - Accessing the Front Part; Door Hinge and Safety Interlock

Technical Support - MDM 76/104 599 77 39-16 Rev. 00
14.3 Accessing the front part
1. Door and Door Hinge
2. Door safety interlock
3. Blade
4. Front panel
14.3.1 Door hinge – Door
To replace the hinge, loosen the screws securing it to the cabinet.
To access the door, loosen the screws joining the two front and rear door
frames together.
14.3.2 Door safety interlock
Remove the iron ring securing the bellow seal to the unit.
Remove the part of the bellow seal concerned from the unit.
Take care not to scratch the cabinet.
Push the pin at the top inwards and at the same time move the door
safety device towards the left.
Holding the top still.
Push the pin at the bottom inwards and at the same time move the door
safety device towards the left.
1
2
3
4
