Electrolux EWX11831 - Belt, Pulley, Motor, and Heating Replacement (Inverter)

Technical Support - MDM 98/104 599 77 39-16 Rev. 00
15.6.2 Plastic pulley ( 273 mm)
See page 85.
15.6.3 Motor
See page 85.
15.6.4 Heating
See page 85.
15.6.5 UIMC
Remove the back panel (see relevant chapter).
Loosen the two screws that fix it to the rear cabinet.
Remove the clamp (shown by the arrow) from the crosspiece, taking care
not to break it.
Remove the heating element connectors.
Pushing the washing unit towards the inside of the appliance remove
the UIMC.
