8.1.3 Failure based on error at the generator „Hardware error“
Generator malfunctioning Title of the message followed by the information below
No high-voltage The voltage of the high voltage source of the TRA3000 F-S-D-V-C
cannot be increased. Press any of the front panel buttons. Repeat the
test. If there is no change contact EMC PARTNER.
High-voltage overshoot The high voltage has exceeded a voltage limit. Press any of the front
panel buttons. Repeat the test. If there is no change contact EMC
PARTNER.
Self firing
The pulse release has been before the trigger released.
Press any of the front panel buttons. Repeat the test. If there is no
change contact EMC PARTNER
No firing
The pulse release has not functioned.
Press any of the front panel buttons. Repeat the test. If there is no
change contact EMC PARTNER
Variac fault
The variac could not be set to the correct value. Please check:
-Is voltage on EUT Power 1?
-variac bridges inserted on the rear panel?
-variac fuse o.k.?
High voltage regulation fault The high voltage regulation of the source is not functioning correctly.
Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
No synchronisation signal Check power voltage on EUT input on rear of TRA3000 and the 16A
fuse. When a external CDN is used, check the voltage on the direct
output of the TRA3000.
ESD fault Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
EFT fault Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
DIPS fault Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
Basis fault Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
SURGE fault Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
HV charge timeout Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
Capacitor voltage to low Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
Communication error Press any of the front panel buttons. Repeat the test If there is no
change contact EMC PARTNER
Bad parameter for this extension Check parameter setting for the selected test set up.
Error on PWR1 Check power voltage on EUT input on rear of TRA3000 and the 16A
fuse.
Error on PWR2 Check power voltage on EUT input on rear of TRA3000 and the 5A
fuse.
