EMC-PARTNER TRA3000 S - Voltage Interruption and Variation with Internal Variac

TRANSIENT3000
23/162
1.3.6 Voltage interruption and Variation with internal Variac EXT-TRA3000 D-V
Voltage range 0 to 260 V when EUT
power input voltage is
230V
EUT
Power
Depending on the EUT
power voltage
Frequency range without variac DC up to 400 Hz external Source
Frequency range with variac involved 48 Hz to 60 Hz external Source
Nominal current 16A without internal
Variac involved
Interruption with internal variac and
linear load
maximum 12 A
maximum 16 A
< 5s
< 300 ms
Inrush current 500 A Peak - 0%,
+30%
Interruption time 50 µs to 30 s phase angle selectable
Amplitude of the interruptions continuously selectable
from 0 to 100 %
IEC: 0 %, 40 %, 70 %, 80%
Phase angle for turn ON and OFF of
the EUT. Selectable in range
0 to 360° ± 5°
Voltage variation with the internal
variac
0 to 110 % maximum.
5A
± 20% 2 s to 30000 s
Voltage variation with external variac 0 to 110 % maximum.
16 A
± 20% 2 s to 30000 s
Less than 1 period
More than one period
d.c. interruption
Interruption within one
period. Input as angle
Interruption longer then
one period. Input in ms
Input in ms
Ramps -Voltage
-Synchronisation angle
-Interruption time
Interruption for all kind of loads
UT= voltage at EUT Power 1
DIP
100 %
% UT
0 % 0 to 16 A
For interruptions of 0 to 100% and 100% to 0% the internal Variac is not involved, therefore the test
can be carried out up to 16 A. For interruption with UT =EUT Power 1 voltage not zero, the internal
variac limits the EUT power current. The maximum allowed current values are listed in the table on
the next page. Please be aware that different types of loads influence the maximum current.
