EMC-PARTNER TRA3000 S - Common Mode Test with EXT-TRA3000 C

TRANSIENT3000
25/162
1.3.9 Common mode test with EXT-TRA3000 C
Caution
To avoid any damage of the EUT during CM test set-up the EUT power cord on the rear side of the
TRA3000 shall be removed. When the CM test is selected the power line is disconnected and the PWR1
and PWR2 can not switched “ON”. As soon as an other test e.g. Surge is selected the PWR1 and PWR2
can be activated and the power voltage is on L at the front of the TRA3000.
1.3.9.1 General Generator Specification
Voltage setting range 0.1 to 35V 0.1 V resolution
Source impedance 50 Ohm ± 10%
Synch turn ON/OFF 0° ± 5% of test voltage
Operation mode: Continuous
Leves V 1 up to 4
Open circuit output voltage range Vmin 0.1V
Vmax 30V
-10%
+10%
Test frequencies DC, 16,7Hz, 50Hz and
60Hz
Test durtion 1 up to 30’000s
Test time 1 up to 30’000s
Operation mode: Short
Leves V 1 and 2
Test frequencies DC, 16,7Hz, 50Hz and
60Hz
Test duration 1 up to 10s
Repetition Duration + 1 s
Test time 1 up to 10s
Operation mode: fix frequencies
Range DC up to 150kHz 1Hz resolution
Operation mode: sweep
frequencies
See chapter below
Levels 1 up to 4
1.3.9.2 Characteristics and performance of the generator for d.c. tests
Test levels for continuous operation 1, 3, 10, 30 V
Test levels for short time operation 10, 30 V 1 to 10s Selectable short duration
time
Switching time at d.c. ON/OFF Between 1 - 5 µs 1Hz resolution
