EMC-PARTNER TRA3000 S - Measuring Circuit and Outputs

TRANSIENT3000
27/162
Synchronisation to Impulse Out
Generally we recommend the synchronisation to the TRA3000 (PWR1 or PWR2). The voltage at the PWR
inputs is limited to 280Vrms.
That the synchronisation via the Impulse Output (Synchro on Output) works correct, the following condition
must be fulfilled:
If frequency <= 100Hz, than the voltage must be > 100Vrms
or
If frequency > 100Hz, than the voltage must be > 150Vrms
Caution
When PWR1 is turned OFF also the synchronisation signal is turned OFF. TRA3000 displays the following
message.
Î Generator Malfunction „No synchronisation signal“
1.3.12 Measuring circuit, measuring outputs
Monitor outputs for measuring equipment e. g. oscilloscope:
Outputs Relations Tolerances Maximum values
SURGE Voltage
SURGE Current
EUT Power Voltage
EUT Power Current
10 V equals 4000 V
10 V equals 2000 A
10 V equals 400 V
10 V equals 100 A
5 %
5 %
3 %
5 %
4800 V
2400 A
480 V
500 A
Numeric measurements e.g. measuring values in the display and in the report.
Display Range Tolerances
SURGE Voltage Peak value
SURGE Current Peak value
EUT Power Voltage (rms)
EUT Power Current (rms)
0 to 5000 V
0 to 2500 A
0 to 280 V
0 to 18 A
3 %
3 %
3 %
3 %
