5 Preparation for Operation
5.1 Attention, Refer to Manual
This manual is an integral part of the TRA3000 F-S-D-V-C. The safety rules and precautions in the
manual must be observed. EMC PARTNER and their representatives accept no responsibility for
damages to persons and equipment as a results of non-observation of the safety rules and
precautions in this manual.
Before connecting the TRA3000 F-S-D-V-C to a public power line, Chapter 3 „Safety must be carefully
studied.
5.2 Operators and Service Personnel
Only trained personnel should carry out EMC tests. For small groups of maximum 10 persons EMC
PARTNER AG offers the following in-house seminars in English or German:
1. EMV Introduction
2. EMV Standardisation
3. EMC „ESD“ immunity test
4. EMC „EFT“ immunity test
5. EMC „SURGE“ immunity test
6. EMC „DIPS“ immunity test
7. EMC „HARMONICS“ immunity test
8. EMC „MAGNETIC FIELD“ immunity test
9. EMC „CW CURRENT INJECTION“ immunity test
10. EMC „CE-MARK“ transient immunity tests
11. „NEMP“ immunity test
12. „AC, DC, IMPULSE“ insulation test
5.3 Checks before operation
5.3.1 Optical verification of the TRA3000 F-S-D-V-C
Before you unpack the TRA3000 F-S-D-V-C, please check whether the packing is deformed or damaged.
When the TRANSIENT is unpacked, also check whether the tester is damaged. If you detect a damage,
please inform EMC PARTNER and the shipping organisation immediately.
5.3.2 Power source check
On the rear panel, you will find a type plate. Please check whether the Tester has been prepared for the
correct power line voltage of your public power. If the power supply voltage is different please inform EMC
PARTNER AG in Switzerland, or your EMC PARTNER AG representatives.
5.3.3 Connecting the TRA3000 F-S-D-V-C to the power line
Please use the supplied power cord for connecting the TRA3000 F-S-D-V-C to your public power supply.
As stated on the rear panel, the power supply must have an earth safety wire. Please check the earth
connection on your power outlet before you connect and turn on the TRA3000 F-S-D-V-C.
