EMC-PARTNER TRA3000 S - TRA3000 Command Overview

11BRemote Ports
136/162
12.4 Overview of TRA3000 F-S-D-V-C Commands
TRANSIENT-3000 Remote Control Commands - v1.00 – 22/02/2010
=====================================================
For each parameter referred by a string in menu, it is possible to give the string as command parameter,
without case sensitivity.
Main Parameters:
TST Test Kind .xx. EFT,ESD,SURGE
DIPAC,DIPDC,
VAR,MF,CM
ESD
VNOM V-charge resp. V-peak (in V) .xx. Integer
POL Polarity .xx. Pos,Neg
NBR Number of Pulses .xx. Integer
REP Repetition (in msec) .xx. Integer
TRIG Trigger Mode .xx. Auto,Man
MO 0=Every Pulse, 1=On Discharge only .xx. Integer or string
MD Discharge mode .xx. Air,Contact,Firing
EFT
VNOM V-charge resp. V-peak (in V) .xx. Integer
POL Polarity .xx. Pos,Neg
TTM Test-Time (in sec) .xx. Integer
ESF Spikes Frequency (in KHz) .xx. Integer
EBD Burst Duration (in ms) .xx. Integer
SYM Syncro Mode .xx. Off,Power,Extern
SYA Syncro Angle (in Deg.) .xx. Integer
REP Repetition (in msec) .xx. Integer
TRIG Trigger Mode .xx. Auto,Man
MD Random-Mode .xx. On,Off
SURGE
VNOM V-charge resp. V-peak (in V) .xx. Integer
POL Polarity .xx. Pos,Neg
NBR Number of Pulses .xx. Integer
REP Repetition (in sec) .xx. Integer
TRIG Trigger Mode .xx. Auto,Man
SYM Syncro Mode .xx. Off,Power,
Output,Extern
SYA Syncro Angle (in Deg.) .xx. Integer
MO 0=CWG 1=MF-1000-1,2=MF-1000-2 .xx. Integer or string
DIPAC
VNOM Dip Level (in %) .xx. Integer
commands short description Valid in „local mode“
Query allowed
Set allowed
Valid in „run mode“
Type of argument
