EMC-PARTNER TRA3000 S - Seltests

TRANSIENT3000
112/162
8.4.2 Seltests
The selftests can be selected as follow:
display when "Main" has been
pressed
display after pressing three time
Menu
after pressing "Service" button
After pressing „ENTER“ the different self tests can be activated.
loaded test EUT power v, i
test parameters
tests parameters
LEDS All LEDS on the front panel can be step by step
checked.
BUTTONS The operation of all buttons on the front panel can
be step by step checked.
POWER The operation of the PWR switches can be
checked. Follow the instruction shown on the
display.
EXT-TRA3000 S The correct operation of the coupling pathses can
be checked. Follow the instruction shown on the
display.
EXT-TRA3000 F The correct operation of the coupling pathses can
be checked. Follow the instruction shown on the
display.
