TRANSIENT3000
29/162
1.4 Mechanical dimensions
Tester -Type Dimensions [mm] Weight [kg] Versions
width x depth x height
TRA3000 F-S-D-V-C and all
Versions
550 x 600 x 190 See standard accessories
list
19" 4 UH
1.5 Power Consumption
The power line input is located on the rear side of the TRA3000 F-S-D-V-C.
Voltage between phase and neutral 100V up to 240V 50 up to 60Hz
Power consumption Standby: power cord connected, switch
turned “OFF”
Power “ON” no EMC test running
Power “ON” EMC test running
< 1W
75W
<150VA
Power cords see next paragraph „Accessories delivered with the TRA3000
1.6 Included articles, dimensions
