NBR Number of Periods or Dip Duration (in msec) .xx. Integer
REP Repetition (in sec) .xx. Integer
TTM Test-Time (in sec) .xx. Integer
TRIG Trigger Mode .xx. Auto,Man
MO 0=“< 1 Period”, 1=“> 1 Period”, 2=“Option 3.2” .xx. Integer or string
MD High-Z at 0% .xx. On,Off
D1B DIP: Dip1 Begin (in Deg.) .xx. Integer
D2B DIP: Dip2 Begin (in Deg.) .xx. Integer
D1E DIP: Dip1 End (in Deg.) .xx. Integer
D2E DIP: Dip2 End (in Deg.) .xx. Integer
D2S DIP: Dip2 selection .xx. on,off
DIPDC
VNOM Dip Level (in %) .xx. Integer
NBR Dip Duration (in msec) .xx. Integer
REP Repetition (in sec) .xx. Integer
TTM Test-Time (in sec) .xx. Integer
TRIG Trigger Mode .xx. Auto,Man
MO 0=“Short Int.” .xx. Integer or string
MD High-Z at 0% .xx. On,Off
VAR
VNOM Nominal Voltage for adjust (in V) .xx. Integer
VATN Variation tn (in s) .xx. Integer
VAMD Variation td mode .xx. abrupt, adjust
VATD Variation td (period) .xx. Integer
VATS Variation ts (period) .xx. Integer
VAL Variation Level (in %) .xx. Integer
VATI Variation ti (period) .xx. Integer
NBR Number of Cycles .xx. Integer
MF
VNOM MF Level (in A/m) .xx. Integer
TTM Test-Time (in sec) .xx. Integer
MO 0=MF1000-1, 1=MF1000-2, 2=MF1000-3, 3=special .xx. Integer or string
CM
VNOM Nominal Voltage (in V) .xx. Integer
NBR Duration (in sec) .xx. Integer
REP Repetition (in sec) .xx. Integer
TTM Test-Time (in sec) .xx. Integer
TRIG Trigger Mode .xx. Auto,Man
MD Freq. Range Frequency unit: “Hz”, “kHz” .xx. String
ESF Freq. Range Frequency (in Hz or kHz, see MD) .xx. Integer
EBD Mains Frequency: “DC”,“16.7Hz”,“50Hz”,“60Hz” .xx. String
MO CM Test: “Mains Freq”, “Freq. Range” .xx. String
MO2 Mains Freq disturbance: “Short”, “Continuous” .xx. String
MO3 Freq. Range mode: “Fix”, “Sweep” .xx. String
Coupling:
EFT
CTO “Impulse-Out”, “EUT-Power”, “CDN-3phase” .xx. String
CL EUT-Power: Coupling to L .xx. On,Off
CN EUT-Power: Coupling to N .xx. On,Off
CP EUT-Power: Coupling to PE .xx. On,Off
CLN EUT-Power: Coupling to L,N .xx. On,Off
CLP EUT-Power: Coupling to L,P .xx. On,Off
CNP EUT-Power: Coupling to N,PE .xx. On,Off
CLNP EUT-Power: Coupling to L,N,PE .xx. On,Off
CL1N CDN-3phase: Coupling to L1 .xx. On,Off
CL2N CDN-3phase: Coupling to L2 .xx. On,Off
CL3N CDN-3phase: Coupling to L3 .xx. On,Off
CN3 CDN-3phase: Coupling to N .xx. On,Off
CP3 CDN-3phase: Coupling to PE .xx. On,Off
