User Manual Chapter 1
GFK-1742F Jan 2020
Product Overview 1
Chapter 1: Product Overview
The Motion Mate DSM314 is a high performance, easy-to-use, multi-axis motion control
module that is highly integrated with the PACSystems RX3i and Series 90-30 host controller
logic solving and communications functions.
The two versions of the DSM314, IC693DSM314 and IC694DSM314 are functionally
identical.
Figure 1
The DSM314 supports two primary control loop configurations:
•
Standard Mode (Follower Control Loop Disabled)
•
Follower Mode (Follower Control Loop Enabled)
