User Manual Chapter 3
GFK-1742F Jan 2020
Installing and Wiring the DSM314 64
3.3.5 Cables
Five cables are available for the DSM314:
Table 19: Cables for the DSM314
Cable
Description
Length
Application
IC693CBL316
Station Manager Cable
1 meter
DSM314 Comm for firmware upgrade
IC693CBL324
Terminal Board Connection
Cable
1 meter
DSM314 to Servo Axis Terminal Board or
Aux Terminal Board
IC693CBL325
Terminal Board Connection
Cable
3 meters
DSM314 to Servo Axis Terminal Board or
Aux Terminal Board
IC800CBL001
Digital Servo Command Cable
1 meter
Digital Servo Axis Terminal Board or DSM
to Digital Servo Amp
IC800CBL002
Digital Servo Command Cable
3 meters
Digital Servo Axis Terminal Board or DSM
to Digital Servo Amp
Custom Terminal Board and Servo cables are available in longer lengths by contacting your
Emerson distributor. The maximum recommended cable length for the DSM connector to
the

and

Series servo amplifier is 50 meters.
The cables use special shielding and construction to ensure reliable servo operation. We
recommend that users do not attempt any field modifications of the cables or connectors.
Note: If a Digital Servo Axis does not use any of the devices that normally connect to the IC693ACC335
Digital Servo Terminal Board screw terminals, the Terminal Board and Terminal Board Cable
IC693CBL324/325 are not needed. Instead, the Digital Servo Command Cable IC800CBL001/002
can be connected directly from the Digital Servo Amplifier to the DSM314 faceplate A or B
connector. When this is done, the OT Limit Sw configuration parameter must be set to Disabled
in the configuration software or the DSM will not operate.
