User Manual Chapter 1
GFK-1742F Jan 2020
Product Overview 14
Table 4: Selected
Series Servo Motor Models
Model Number
Torque Nm
Output KW
Max. Speed (RPM)
1
1
0.3
3000
2
2
0.4
2000
2
2
0.5
3000
3
3
0.9
3000
6
6
1.0
2000
6
6
1.4
3000
12
12
2.1
2000
12
12
2.8
3000
22
22
3.8
2000
22
22
4.4
3000
30
30
3.3
1200
30
30
4.5
2000
30
30
4.8
3000
40
38
5.9
2000
40/Fan
56
7.3
2000
1.5 Section 4: Series Servos (Digital Mode)
The Digital
Series Servo features include:
World leading reliability
Low maintenance, no component drift, no commutator brushes
All parameters digitally set; no re-tuning required
Absolute encoder eliminates re-homing (optional battery kit required)
Optional motor brake
High resolution (32K Beta) (64K Beta M) count per revolution encoder
The
Series Servos offer the highest reliability and performance. The latest technologies,
such as high-speed serial encoders and high efficiency Integrated Power Modules, further
enhance the performance of the servo system. Designed with the motion control market in
mind, the
Series Servo Drives is ideally suited for the packaging, material handling,
converting, and metal fabrication industries.
The servo system is unique in that all the control loops - current, velocity, and position - are
closed in the motion controller. This approach reduces setup time and delivers significant
throughput advantages even in the most challenging applications.
The servo drives are less costly to integrate and maintain. Control circuits are unaffected by
temperature changes. There are no personality modules. The servos have a broad
application range including a wide load inertia range, flexible acceleration/deceleration and
position feedback configurations. Extensive software customization features are available
to optimize performance and overcome machine limitations.
