Emerson Liebert DS Series User Manual

Liebert DS Components and Nomenclature
4
Figure 2 Upflow model component locations
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1. Liebert iCom Control Display
2. Electric Box
3. Filters
4. Evaporator Coil
5. Motor
6. Blower
7. Fan Pulley
8. Motor Sheave and Belts
9. Compressor Section
10. Infrared Humidifier (optional)
11. Disconnect (optional)
12. Condensate Pump (optional)
13. Smoke Sensor (optional)
14. Condenser Cleanout Plugs (fluid cooled units only)
15. Condenser Drain Plugs ( fluid cooled units only)
16. Econ-O-Coil Valve (GLYCOOL/Dual Cooling)
17. Variable Frequency Drive (optional on
Digital Scroll units only)
DPN001222
Rev. 1

Emerson Liebert DS Series Specifications

General

Brand	Emerson
Model	Liebert DS Series
Category	Heat Pump
Language	English
