Liebert DS Components and Nomenclature
3
1.0 LIEBERT DS COMPONENTS AND NOMENCLATURE
Figure 1 Downflow model component locations
14
1. Liebert iCOM
2. Electric Box
3. Filters
4. Evaporator Coil
5. Motor
6. Blower
7. Fan Pulley
8. Motor Sheave and Belts
9. Compressor Section
10. Infrared Humidifier, optional
11. Disconnect, optional
12. Condensate Pump, optional
13. Smoke Sensor, optional
14. Condenser Cleanout Plugs, fluid-cooled units only
15.Condenser Drain Plugs, fluid-cooled units only
16. Econ-O-Coil Valve, GLYCOOL/Dual Cooling
17. Variable Frequency Drive (optional on
digital scroll units only)
18. EC Fans, optional
DPN000958
Rev. 3
3
1
17
11
2
9
15
4
16
10
12
6
8
5
18
18
7
13
