Maintenance
131
13.1 Filters
NOTICE
Risk of improper filter installation and filter collapse. Can cause equipment damage.
Pleat direction is non-standard. Use only short-pleat filters (see Figure 97). Long-pleat filters
are subject to collapse at high airflows.
To maximize the performance and reliability of Liebert DS equipment, use only Liebert filters.
Contact your local Emerson representative to order replacement filters.
Table 59 Filter quantities, downflow units
Unit Size
Filter Size
Width x Length
Filter Quantities
4" Filter Option
Merv 8 or Merv 11
2" Primary / 2" Pre-Filter Option
Merv 11 Primary Filter / Merv 7 Pre-Filter
DS 028, 035, 042
16 x 25
55/5
DS 053, 070, 077 7 7/7
DS 105 9 9/9
Table 60 Filter quantities, upflow units
Upflow Models
Filter Size
Width x Length
Filter Quantities
4" Filter Option Merv 8 or Merv 11
2" Primary/2" Pre-Filter Option
Merv 11 Primary/Merv 7 Pre-Filter
VS025, 035, 042
25 x 20"
44/4
VS053, 070, 077 6 6/6
VS105 8 8/8
