14
Connect audio peripherals to the ports labeled as “AUDIO-IN” and “AUDIO-OUT” on
the DVR. These support devices for capturing or broadcasting sound.
Connect the IR Extender (Optional)
Connect the IR extender cable to the port labeled as “IR_ext” on the DVR. The cable is
an optional device which serves as an IR controller extension.
Connect the Power Adaptor
Connect the Power Adaptor to the DC jack labeled as “DC-IN 12V” on the DVR.
Connect the power adaptor after all devices have been properly installed.
