Technical data Proline Promag 53 MODBUS RS485
128 Endress+Hauser
Promag P
!
Note!
The following weights apply to standard pressure ratings and without packaging material.
Promag H
!
Note!
The following weights apply to standard pressure ratings and without packaging material.
Nominal
diameter
Weights in [lbs] for the Promag P
Compact version Remote version (without cable)
Sensor Transmitter
[inch] ANSI/AWWA ANSI/AWWA
½"
Class 150
14
Class 150
10 13
1" 16 12 13
1 ½" 21 16 13
2" 23 19 13
3" 31 26 13
4" 35 31 13
6" 56 52 13
8" 99 95 13
10" 165 161 13
12" 243 238 13
14" 386 381 13
16" 452 448 13
18" 562 558 13
20" 628 624 13
24" 893 889 13
Promag transmitter (compact version): 7.5 lbs
High-temperature version: + 3.3 lbs
Nominal
diameter
Weights in [lbs] for the Promag H
Compact version Remote version (without cable)
[inch] Sensor Transmitter
1/12" 11.5 4.4 13.5
5/32" 11.5 4.4 13.5
5/16" 11.7 4.4 13.5
½" 11.9 4.2 13.5
1" 12.1 6.2 13.5
1½" 14.3 9.9 13.2
2" 19.8 15.5 13.2
3" 41.9 37.5 13.2
4" 40.8 36.5 13.2
Promag transmitter (compact version): 7.5 lbs
