DSG-423 FUEL SYSTEM
04-5
Wiring Diagrams
Revision Level
The following wiring schematics are taken from the wiring diagram labeled below:
Fuel Injectors
676466566
Injector #1
Injector #2
Injector #3
Injector #4
16 TN
GCP
Injector #3 LS
Injector #2 LS
Injector #4 LS
Injector #1 LS
16 WH 16 BN/YE 16 BN/LB
F5 15A
Relayed Power
16 RD 16 RD 16 RD
16 RD
16 RD
