DSG-423 ENGINE CONTROLS
08-11
Diagrams and Schematics
Symbols
+
Resistor or heating element Potentiometer (pressure or temperature) Potentiometer (outside influence) Battery Fuse Circuit breaker
Heating element, conductor loop
Connector attached to component lead (pigtail) Connector attached to component Component with screw terminals Component case directly attached to metal part of equipment (ground) Part of a component
Entire component
Distributed splice
Crossed wiring without connection
Male connector Female connector Connector Ground Removable connection Splice
