DSG-423 ENGINE CONTROLS

08-12

GCP - Power Distribution Box

Fuse Amps Circuits protected

1 10 Battery Voltage to EPR

2 5 Ignition Voltage to GCP and Relays

3 10 Battery Voltage to GCP

4 15 Fuel pump

5 15 Battery Voltage out of Power Relay

6 - Not used

Fuel pump

Starter

Empty

Relay

Part of -5250010- Wiring Harness

Power

Relay
