DSG-423 FUEL SYSTEM
04-9
Wiring Diagrams
Revision Level
The following wiring schematics are taken from the wiring diagram labeled below:
Engine Controls - Dry Fuel EPR
EPR
16 RD/LB
F1
10A
7
Power
GCP
Twist
per foot
1514
(min.)
10 turns
18 DG/VT
18 OG/LG
18 OG/LG
18 DG/VT
CAN+ CAN-
71
CAN1+
CAN1-
Twist
per foot (min.)
10 turns
Ground
6
18 BK/WH
12 BK/WH
Grounding
Ring
