DSG-423 CHARGING SYSTEM
06-14
SPECIFICATIONS
GENERAL SPECIFICATIONS
Generator output 65/110 max. amps @ 1800 -
6000 generator rpm (approx.
500 - 2000 engine rpm).
Battery Motorcraft 12 Volt
540 CCA (at -18°C (0°F)
58 amp/hr.
Battery Charging Voltage 13 - 15.5 volts
TORQUE SPECIFICATIONS
Description Nm lb.ft. lb.in.
Generator mounting bolts 25 18
Regulator attachment screws 3 27
Battery cable nuts 6 53
Generator pulley nut 109 80
Generator wiring nuts 8 71
SPECIAL TOOLS
VAT-40 Starting/charging
Tester
078-00005
