DSG-423 STARTER
07-4
Wiring Diagram
Revision Level
The following wiring schematics are taken from the wiring diagram labeled below:
Starting System
Starter
Relay
86
18 RD/LG
Fuse Panel
F2
5A
Switched Ignition
GCP
72
Starter
85
87
30
87A
42 Pin
Conn.
19 15
Starter
Solenoid
Ring
16 LB/PK
16 LB/PK
16 WH/PK
Start in
Auto
Crank
Start in
Interrupt
18 LG/VT
18 RD/LG
18 RD/LG
18 RD/LG
