DSG-423 STARTER
07-6
Symptom Chart
CONDITION POSSIBLE SOURCE ACTION
Starter does not crank (audible click may or
may not be heard)
Open fuse Check fuse continuity
Low battery Refer to battery diagnosis in section 6
Defective remote relay Check relay
Open circuit or high resistance in external
feed circuit to starter solenoid
Check starter wiring
Defective starter Replace starter motor
Defective neutral park switch Replace switch
Unusual starter noise Starter not mounted flush (cocked) Realign starter on transmission bell housing
or SAE housing
Noise from other components Investigate other powertrain accessory noise
contributors
Ring gear tooth damage or excessive ring
gear runout
Replace flywheel ring gear
Defective starter Replace starter motor
Starter spins but the engine does not crank Starter not mounted flush (cocked) Realign starter on transmission bell housing
or SAE housing
Ring gear tooth damage Replace flywheel ring gear
Starter cranks but engine does not start Problem in fuel system Refer to fuel system section 4
Engine related problem Refer to Section 01, Diagnosis and Testing
Starter cranks slowly Low Battery Charge or replace battery -- refer to section 6
High resistance or loose connections in
starter solenoid battery feed or ground
circuit.
Check that all connections are secure
Ring gear runout excessive Replace ring gear
Defective starter Replace starter motor
Starter remains engaged and runs with
engine
Shorted ignition switch Replace ignition switch
Battery cable touching solenoid “S” terminal
(defective or mispositioned cable)
Replace or relocate cable
Defective starter Replace starter motor
Starter clicks and engages but engine will
not crank
Hydrolocked cylinder Remove all plugs one at a time while
checking for fluid in cylinders
Seized main or rod bearing Repair as needed - Refer to Section 01
