DSG-423 STARTER
07-10
SPECIFICATIONS
GENERAL SPECIFICATIONS
Current draw NO load 60 - 80 AMPS
Current draw NORMAL load
Current draw MAX. load 800 AMPS
Minumum stall torque
(@5 volts)
14.7 Nm (16 lb-ft)
Cranking speed 140 - 220 RPM
Max. voltage drop
(normal operating temp.)
TORQUE SPECIFICATIONS
Description Nm lb.ft. lb.in.
Mounting bolts/nuts/studs 27 20
Battery cable nuts 6 53
Solenoid terminal nut 5 44
Solenoid terminal B+ nut 12 9
SPECIAL TOOLS
VAT-40 Starting/charging
Tester
078-00005
