DSG-423 IGNITION SYSTEM
03-4
Wiring Diagram
GCP
Spark
Ignition
16 RD
Fuse Panel
F5
15A
Relayed Power
16 RD
16 RD 16 RD 16 RD 16 RD
Cylinder
Coil 1B
Spark
Ignition
Cylinder
Coil 2A
Coil
3
Coil
4
Spark
Ignition
Coil 2B
Coil
2
Spark
Ignition
Coil 1A
Coil
1
Cylinder Cylinder
16 RD 16 RD 16 RD 16 RD
18 WH/PK 18 YE/RD 18 DG/VT 18 YE/BK
