Epson AcuLaser MX14 - Rear View

Rear View
Epson AcuLaser MX14NF
13
12
11
10
9
8
7
3
6
1
2
4
5
1ADF Cover 2Ethernet Port
3 USB Port 4 Wall Jack Connector
5 Phone Connector 6 Rear Cover Handle
7 Power Connector 8 Rear Cover
9 Transfer Roller 10 Paper Chute
11 Paper Feed Roller 12 Photoconductor Drum
13 Levers
Epson AcuLaser MX14
9
8
7
6
5
4
3
1
2
