The valid data for each barcode type is described below. If invalid data is
included in the barcode data string, the barcode is not printed.
Barcode type Barcode data
EAN-13
EAN-8
UPC-A
UPC-E
Interleaved 2 of 5
POSTNET
Code 39
Code 128
0-9 (Hex 30-39)
0-9 (Hex 30-39)
0-9 (Hex 30-39)
0-9 (Hex 30-39)
0-9 (Hex 30-39)
0-9 (Hex 30-39)
0-9 (Hex 30-39), (Hex 41-5A), (Hex 20, 24, 25, 2B, 2D,
2E, 2F)
Set A, Set B, Set C
The following conditions are required for barcode printing:
T Barcode printing is always performed unidirectionally. However,
when it is mixed with raster bit image data, neither barcode nor raster
bit image data is printed.
T A barcode is not printed when part of the barcode extends beyond
the right margin.
T When barcode data and text data are mixed in a data sequence,
barcodes and text are printed in the same place.
T The start and stop (*) characters of Code 39 are added to human
readable characters.
T The initial data of Code 128 (Set A, B, or C) is identified as the first
data of Code 128, and must be hexadecimal (41, 42, and 43,
respectively).
T When Code 128 Set C and Interleaved 2 of 5 are selected, barcode
data requires an even number data string. However, if an odd
number string is sent, a 0 is automatically added, making it an even
number data string.
T The barcode print start position (except for POSTNET) is always
7/72 inch above the baseline.
L
Sun-G+ Rev.C
A5 size Appendix c
97/11/13 pass 0
C-14 Specifications
