Epson L1800 Service Manual

L1800 Revision A
Adjustment Adjustment Using Adjustment Program 121
Confidential
4.2.5 PF adjustment
 PF- for standard print area
The following pattern is printed.
Figure 4-5. PF (standard print area) Adjustment Printout Pattern
How to Judge
Examine the printout patterns, and enter the value for the pattern with no overlap and
gap between the upper and lower ones.
 PF- for bottom margin area
The following pattern is printed.
How to Judge
Examine the printout patterns, and enter the value for the pattern with no overlap and
gap between the upper and lower ones.
Figure 4-6. PF (bottom margin area) Adjustment Printout Pattern
Additional information
When overlap and gap are observed in the all patterns, enter the value for the best one,
and print the adjustment pattern again.
C H E C K
P O I N T
Example for judgement
1
-1
-3
-5
0
-2
-4
OK NGNG
C H E C K
P O I N T
Example for judgement
23456781
Upper pattern
Lower pattern
OK NGNG
Overlap
Gap
